Formlabs Nylon 11 CF Powder (PA11, SLS)
Formlabs · SLS powder
A carbon-fiber-filled PA11 powder for strong, lightweight, impact-resistant parts that remain stable at elevated temperatures.
Formlabs datasheet values, printed parts
Other PA11 grades and fills
Compare the PA11 products and conditions in the library; see the grade overview at PA11.
- COND
- FR
- ESD
- GF
- Arkema Rilsan Invent Natural
- EOS PA 1102 black
- EOS PA 1101 ClimateNeutral
- Formlabs Nylon 11
- EOS PA 1101
- Forward AM Ultrasint PA11
- HP PA 11
- HP PA 11 Gen2
- Sinterit PA11 Onyx
- CF
- Formlabs Nylon 11 CF
- Sinterit PA11 CF
- Forward AM Ultrasint PA11 Black CF
Compare all 17 grades and fillsHide
| Grade · open for datasheet | Best for | Yield MPa | Tensile MPa | Elong. % | Hardness |
|---|---|---|---|---|---|
Conditioned | PA11 moisture-conditioned to equilibrium at 50% RH: water plasticizes the amide phase, lowering modulus and strength while raising ductility and impact toughness. | 36 | 45 | 120 | 72 Shore D |
Flame-retardant PA11 powder | Specify for aircraft interior, rail and electrical enclosure parts needing V-0 / FAR 25.853 compliance. | 36 | 40 | 15 | 76 Shore D |
Static-dissipative / conductive-filled PA11 powder | For electronics handling trays, fuel-system components and fixtures requiring controlled surface resistivity. | 38 | 44 | 15 | 77 Shore D |
Glass-bead / glass-fiber filled PA11 powder | Use when stiffness, dimensional stability and elevated-temperature rigidity matter more than ductility. | — | 42 | 6 | 82 Shore D |
SLS powder | — | — | 45 | 45 | 77 Shore D |
SLS powder | — | — | 48 | 30 | — |
SLS powder | — | — | 48 | 45 | — |
Formlabs Nylon 11 Powder · SLS powder | A bio-based, highly ductile PA11 powder for flexible, impact-resistant functional and medical parts. | — | 49 | 40 | — |
SLS powder | — | — | 50 | 30 | 75 Shore D |
SLS powder | — | — | 52 | 28 | — |
HP 3D High Reusability PA 11 · MJF powder | A ductile bio-based PA 11 for impact-resistant functional parts, living hinges, and flexible production geometries. | — | 52 | 50 | 80 Shore D |
HP 3D High Reusability PA 11 Gen2 · MJF powder | A second-generation ductile bio-based PA 11 for repeatable final-use production with improved powder efficiency. | — | 52 | 35 | — |
SLS powder | — | — | 55 | 31.6 | 76 Shore D |
Carbon-fiber reinforced PA11 powder | Highest stiffness-to-weight printed PA11; for jigs, brackets and motorsport parts where deflection must be minimized. | 60 | 65 | 5 | 82 Shore D |
Formlabs Nylon 11 CFThis page Formlabs Nylon 11 CF Powder · SLS powder | A carbon-fiber-filled PA11 powder for strong, lightweight, impact-resistant parts that remain stable at elevated temperatures. | — | 69 | 9 | — |
SLS powder | — | — | 81 | 24.5 | 81 Shore D |
SLS powder | — | — | 82 | 7 | — |
What is Formlabs Nylon 11 CF Powder?
Formlabs Nylon 11 CF Powder is Formlabs' PA11 (CF-filled) powder for Selective Laser Sintering on Fuse 1+ 30W — a carbon-fiber-filled PA11 powder for strong, lightweight, impact-resistant parts that remain stable at elevated temperatures. Formlabs Nylon 11 CF Powder has a tensile strength of 69 MPa (10 ksi), stronger than 75% of polymer grades. Elongation at break is 9% and the elastic modulus is 5.3 GPa (0.769 Msi). Pick Formlabs in the Powder row when quoting PA11 and the part is printed from this powder.
Advantages
- Stiff — 5.3 GPa (0.769 Msi), better than 88% of polymer grades
About this powder
“Nylon 11 CF Powder is a carbon fiber-filled material, perfect for applications that require both superior stiffness and strength. Produce lightweight, rigid parts that remain structurally and thermally stable and can sustain repeated impact.” — Formlabs, product description
- Manufacturer
- Formlabs
- Product
- Nylon 11 CF Powder
- Base polymer
- PA11 — carbon-fibre reinforced
- Process
- Selective Laser Sintering (SLS)
- Printers
- Fuse 1+ 30W
- As-printed colour
- Black — Carbon-fibre filled — prints black
- Build envelope
- 165 × 165 × 300 mm. Usable part size depends on orientation, spacing and process allowances.
- Build atmosphere
- Inert atmosphere specified; confirm the gas and settings for the printer/material profile.
- Powder refresh
- 30 % fresh powder in the recorded recipe. Follow the manufacturer’s build and powder-management conditions.
- Formlabs categories
- Impact Resistant · High Stiffness · Temperature Resistant
- Reported material classifications
- Skin Contact · Mucosal Membrane Contact · ISO 10993-5 · ISO 10993-10 · ISO 10993-23 · Long term (>30 day) surface (intact skin) contact. Scope and test conditions apply; these do not certify the finished part or assembly.
- Manufacturer data source
- Formlabs source reference (Rev 02 2023-08-08)
- FabDigit material reference
- Download reference PDF — FabDigit layout with Formlabs data and source attribution.
- Ordering
- Select it in the Powder row when quoting PA11. The quote confirms the selected material and process.
Formlabs positions it for manufacturing aids, rapid tooling, end-use parts, rapid prototyping, replacement and spare alternatives to metal parts, high-impact equipment and functional composite prototypes.
Choosing Nylon 11 CF Powder
A Fuse-series carbon-fibre PA11 for stiff, lightweight functional components where black as-printed appearance is acceptable.
- Consider it for
- Stiff jigs and fixtures · Lightweight brackets · Thermally demanding functional prototypes
- Tradeoffs
- CF reinforcement improves stiffness but reduces compliance and brings orientation sensitivity. It is still a printed polymer composite, not a blanket replacement for metal or a certified conductive part.
- Design and validation
- Keep loads in the stronger plane where possible, avoid sharp internal corners, and validate loaded threads, inserts and fatigue features on representative production orientation.
- Finishing
- Black is the inherent as-printed appearance and is not a dye base. Any abrasive cleanup may change the surface fibre appearance.
- Before choosing
- Does the geometry need compliance that unfilled Nylon 11 offers? Are high temperature and rigidity worth the lower strain margin?
Selection notes based on Formlabs Nylon 11 CF Powder TDS, Rev 02. Published test results depend on the stated printer, orientation and conditioning. Compare material families · Choose a finishing route.
Formlabs Nylon 11 CF Powder properties
Typical values for Formlabs Nylon 11 CF Powder (Rev 02 2023-08-08); review each property’s test condition. Only this product’s reported properties are shown; unreported properties are omitted. Bars are the position among polymer grades.
Mechanical6
Formlabs Nylon 11 CF Powder has a tensile strength of 69 MPa (10 ksi), stronger than 75% of polymer grades. Elongation at break is 9% and the elastic modulus is 5.3 GPa (0.769 Msi).
per ASTM D638-14 Type 1; X 69 / Y 52 / Z 38
per ASTM D638-14 Type 1; X 5.3 / Y 2.8 / Z 1.6
per ASTM D638-14 Type 1; X 9 / Y 15 / Z 5
per ASTM D790-15
per ASTM D790-15
per ASTM D256-10
Thermal3
per ASTM D648-16
per ASTM D648-16
per ASTM D1525
Use published values for design screening. Confirm the grade, build direction, conditioning and available lot documentation when quoting.
Test basis and additional results
Read the values with the specimen preparation and test conditions that produced them.
- Manufacturer document
- 2201694-TDS-ENUS-0 · Rev 02 · 2023-08-08
- Specimen preparation
- Fuse 1+ 30W; specimens conditioned at 23 °C and 50% relative humidity for 7 days before testing.
- Build direction
- Tensile strength, tensile modulus, and elongation report X, Y, and Z values. Flexural, impact, and thermal rows do not state an orientation.
The reviewed reference copy was prepared 2022-06-22 and revised 2023-08-08.
Solvent compatibility screen
24 h immersion mass change reported by the manufacturer
| Solvent | 24 h weight gain |
|---|---|
| Acetic acid 5% | 0.2% |
| Acetone | 0.2% |
| Bleach (~5% NaOCl) | 0.2% |
| Butyl acetate | 0.2% |
| Diesel fuel | 0.6% |
| Diethyl glycol monomethyl ether | 0.5% |
| Hydraulic oil | 1.0% |
| Hydrogen peroxide (3%) | 0.2% |
| Isooctane | 0.0% |
| Isopropyl alcohol | 0.2% |
| Mineral oil (heavy) | 1.0% |
| Mineral oil (light) | 1.3% |
| Salt water (3.5% NaCl) | 0.2% |
| Skydrol 5 | 0.8% |
| Sodium hydroxide solution (0.025%, pH 10) | 0.2% |
| Strong acid (concentrated HCl) | 0.8% |
| TPM | 0.8% |
| Water | 0.1% |
| Xylene | 0.2% |
TDS test article: 1 × 1 × 1 cm cube described as printed and post-cured. No SLS post-cure procedure is defined. This wording does not establish an SLS post-cure requirement. Weight change alone does not establish sealing, retained strength, or long-term chemical life.
Biocompatibility endpoint results
ISO 10993 endpoints listed in the manufacturer TDS
| Standard / endpoint | Result |
|---|---|
| ISO 10993-5:2009 | Not cytotoxic |
| ISO 10993-23:2021 | Not an irritant |
| ISO 10993-10:2021 | Not a sensitizer |
Manufacturer material-sample result for long-term (>30 day) surface contact with intact skin. It does not qualify a finished part or device.
How to interpret this data
The TDS says properties may vary with part geometry, print orientation, and temperature.
The solvent section says printed and post-cured but defines no SLS post-cure. This wording does not establish an SLS post-cure requirement.
This TDS does not publish powder moisture, printed-part water absorption, or a UL 94 result.
Formlabs Nylon 11 CF Powder — frequently asked
What is Formlabs Nylon 11 CF Powder used for?
A Fuse-series carbon-fibre PA11 for stiff, lightweight functional components where black as-printed appearance is acceptable. Consider it for stiff jigs and fixtures, lightweight brackets and thermally demanding functional prototypes. CF reinforcement improves stiffness but reduces compliance and brings orientation sensitivity. It is still a printed polymer composite, not a blanket replacement for metal or a certified conductive part.
What should I validate before using Formlabs Nylon 11 CF Powder?
Keep loads in the stronger plane where possible, avoid sharp internal corners, and validate loaded threads, inserts and fatigue features on representative production orientation. Does the geometry need compliance that unfilled Nylon 11 offers? Are high temperature and rigidity worth the lower strain margin?
How can Formlabs Nylon 11 CF Powder be finished?
Black is the inherent as-printed appearance and is not a dye base. Any abrasive cleanup may change the surface fibre appearance.
How should I interpret the published values for Formlabs Nylon 11 CF Powder?
Fuse 1+ 30W; specimens conditioned at 23 °C and 50% relative humidity for 7 days before testing. Tensile strength, tensile modulus, and elongation report X, Y, and Z values. Flexural, impact, and thermal rows do not state an orientation. Read each value with the stated method, specimen preparation and conditioning.
Sources
Product values come from the selected manufacturer source and are normalised for comparison. Confirm the quoted process, build direction, conditioning and available lot documentation for the finished part.
